Description
Engine/General Specifications
| Configuration | Console |
|---|---|
| Printing Process | 4-drum dry electrostatic transfer system with internal transfer belt |
| Control Panel | 10.1″ Smart Operation Panel |
| Color/Black & White | Color |
| Output Speed Copy/Print | 80 ppm |
| First Page Out Time | Color: 6.4 seconds/B&W: 4.8 seconds |
| Warm-Up Time | 40 seconds |
| Resolution | Copy: 600×600 dpi |
| System Memory | 4 GB RAM 640 GB HDD (320 GB x 2) |
| Maximum Copy Quantity | Up to 9,999 copies |
| Duplexing | Automatic (Standard) |
| Document Feeder Type | Single Pass Duplex Feeder (SPDF) |
| Zoom Range | 25% to 400% in 1% increments |
| Supported Paper Sizes | SRA3+, SRA3, A3, Letter, Legal, Ledger, A5, A6, B4, B5, B6 |
| Supported Paper Weights | Trays: 52 – 256 g/m2 Bypass: 52 – 300 g/m2 Duplex: 52 – 256 g/m2 |
| Supported Paper Types | Plain, Recycled, Color, Special Paper, Letterhead, Preprinted, Prepunched, Bond, Cardstock |
| Standard Paper Capacity | 3,700 sheets |
| Maximum Paper Capacity | 8,100 sheets |
| Standard Output Capacity | 500 sheets |
| Maximum Output Capacity | 3,500 sheets |
| Power Source | 208V – 240V / 12A, 60Hz |
| Typical Electricity Consumption (TEC) | 1.681 kWh/week |
| Power Consumption | Maximum: Less than 2,400 W Sleep: 0.74 W |
| Energy Star | Certified |
| EPEAT Status | Gold |
| Dimensions W x D x H | 29.5″ x 34.7″ x 48.3″ (750 x 880 x 1,225 mm) |
| Weight | 551 lbs (250 kg) |
Printer Specifications
| Processor Speed | Intel® Apollo Lake Processor 1.6 GHz |
|---|---|
| Hard Disk Drive | 640 GB (320 GB x 2) |
| Interfaces | Standard: Ethernet 10 base-T/100 base-TX/1000 base-T, USB Host Type A, USB Device I/F Type B, Bluetooth (Smart Panel Only), Wireless LAN (IEEE 802.11 b/g/n) (Smart Panel Only), USB Host I/F, SD slot, NFC tag, USB Device (TypeB:1Port) Optional: Wireless LAN (IEEE 802.11a/b/g/n), RJ45 I/F (Only Copy connect), Ethernet Print only RJ-45 network port |
| Network Protocol | TCP/IP (IPv4, IPv6) |
| Supported Operating Systems | Windows: Windows® 7/8.1/10, Windows® Server 2008/2008R2/2012/2012R2/2016, Windows® Server 2019 MacOS: Macintosh OS X v10.12 or later Unix: UNIX Sun® Solaris, HP-UX, SCO OpenServer, RedHat® Linux, IBM® AIX, XenDesktop, Citrix XenApp SAP: SAP® R/3® , SAP® S/4® |
| Printer Languages | Standard: PCL5c, PCL6, PostScript 3 (emulation), PDF direct (emulation) Optional: Genuine Adobe® PostScript® 3™, IPDS, PDF Direct from Adobe® |
| Print Resolution | 2400×4800 dpi |
Scanner Specifications
| Scan Speed (B&W & Full Color) | 120 ipm (simplex) / 240 ipm (duplex) |
|---|---|
| Scanning Resolution | 1,200 dpi |
| File Formats | Single page: TIFF, JPEG, PDF, High compression PDF, PDF/A Multi page: TIFF, PDF, High compression PDF, PDF/A |
| Scan Modes | E-mail, Folder, USB, SD Card, URL, FTP, SMB |
Fax Specifications
| Fax Standard/Optional | Standard |
|---|---|
| Type | ITU-T (CCITT) G3 |
| Circuit | PSTN, PBX |
| Fax Resolution | Standard mode: 8 x 3.85 line/mm, 200 x 100 dpi Detail mode: 8 x 7.7 line/mm, 200 x 200 dpi Super fine mode: 8 x 15.4 line/mm, 16 x 15.4 line/mm, 400 x 400 dpi (with optional SAF memory) |
| Compression Method | MH, MR, MMR, JBIG |
| Modem Speed | 33.6 Kbps |
| Transmission Speed | G3: approximately 2 seconds (200 x 100 dpi, JBIG, ITUT #1 chart TTI off, memory transmission)/G3: approximately 3 seconds (200 x 100 dpi, MMR, ITUT #1 chart TTI off, memory transmission) |
| SAF Memory | Standard: 4 MB (approximately 320 pages) Optional: 60 MB (approximately 4,800 pages) |
| Memory Backup | 1 hour |
