Description
System Specifications
Print/Copy Process | 1-drum dry electrostatic transfer with indirect image transfer system |
---|---|
Fusing | Oil-less belt-fusing method |
System Memory | 2 GB RAM / 640 GB (320 x 2) HDD |
CPU | Intel® Atom® Processor BayTrail – 1.91 GHz |
Interface | Ethernet (1000BASE-T/100BASE-TX/10Base-T) USB 2.0 Type A (2 ports on Controller board and 4 ports on operation panel) USB 2.0 Type B (1 port on Controller board), SD slot (1 on operation panel) |
Document Feeder Type | Standard 220-Sheet ADF with single-pass color duplex scanning |
Control Panel | Full-color 17″ Smart Operation Touch Panel |
Copy Resolution | VCSEL: 2400 × 4800 dpi Copy: 1200 × 1200 dpi |
Print Resolution | VCSEL: 2400 × 4800 dpi Print: 1200 × 1200 dpi |
Scan Resolution | 100/150/200/300/400/600 dpi 200 dpi (Default) |
Scan Speed BW Full Color | Simplex: 120 ipm; Duplex: 220 ipm (B&W and Full-color) |
Output Speed | Pro 8310s/8310: 111 ppm Pro 8320s/8320: 136 ppm |
Paper Capacity | Tray 1: 2,200 sheets (1,100 × 2) Trays 2 – 3: 1,100 sheets (550 × 2) |
Paper Size | Tray 1: 8.5″ × 11″ Trays 2 – 3: 5.5″ × 8.5″ to 13″ × 18″ |
Paper Weight | Trays 1 – 3: 14 lb. Bond – 95 lb. Cover (52 – 256 g/m2) |
Max Monthly Volume | 1,000K |
Power Requirements | 208-240 V, 50/60 Hz, 20 A (dedicated) |
Maximum Power Consumption | Pro 8310s: Less than 3,020 W Pro 8310: Less than 2,820 W Pro 8320s: Less than 3,270 W Pro 8320: Less than 3,070 W |
Typical Electricity Consumption TEC | Pro 8310s: 14.2 kWh/wk Pro 8310: 14.0 kWh/wk Pro 8320s: 17.8 kWh/wk Pro 8320: 17.5 kWh/wk |
Dimensions W x D x H | 45″ × 35.4″ × 68.3″ (1,141 × 900 × 1,735 mm) with Attention Light |
Weight | Pro 8210s/8220s: 944 lbs. (428 kg) Pro 8210/8220: 911 lbs. (413 kg) |
Copier Features | Duplex Copying, Simplified Display, Auto Paper Selection, Auto Reduce/Enlarge, Auto Start, Auto Tray Switching, Auto Image Density, User Codes (1,000), Job Programs (50), Image Rotation, Interrupt Copy, Job Presets, Book/Series/Combine Copying, Cover/Chapter/Slip Sheet, Tabs, Sample Copy, Stamps/Numbering, Bates Numbering, Shift/Erase/Margin Adjustment, Customizable Home Screen, Eco-Friendly Indicator, Energy Saver, Weekly Timer, External USB Keyboard Support, Web Browser, Copy Reservation (10), A3/DLT Counter, Mixed Sizes, Batch Mode |
