Description
Engine Specifications
| Configuration | Desktop |
|---|---|
| Color / Black & White | Black & White |
| Technology | Electro photographic printing system with laser beam scanning |
| Operation Panel | 10.1″ Smart Operation Panel color touchscreen with integrated USB 2.0 host port and SD Card slot |
| Black & White Speed | 60 ppm |
| Maximum Monthly Volume | 53,000 prints |
| First Print Speed | 2.2 seconds or less |
| Warm-Up Time | 21 seconds or less (from Main Switch On) |
| Recovery from Sleep Mode | 7.0 seconds or less |
| Print Resolution | 1200×1200 dpi |
| Standard Paper Capacity | 550-Sheet Paper Tray 1 550-Sheet Paper Tray 2 100-Sheet Bypass Tray (1,200 sheets standard capacity) |
| Maximum Paper Capacity | 4,700 sheets |
| Optional Paper Capacity | 550-Sheet x 2 Paper Feed Unit or 2,000-Sheet Large Capacity Tray (LCT); 1,500-Sheet Large Capacity Tray (LCT) |
| Output Capacity | Standard: 500 sheets, face down (8.5″ x 11″ or smaller); 250 sheets, face down (8.5″ x 14″ or larger) Maximum: Up to 4,000 sheets with Finisher, Bridge Unit and 4-Bin Mailbox |
| Supported Paper Sizes | Standard Trays 1 and 2 and Optional Paper Feed Units: User adjustable up to 12″ x 17″ including Letter (8.5″ x 11″), Legal (8.5″ x 14″), Exec (10.5″ x 7.25″), Ledger (11″ x 17″), A3, A4, A5, A6; Custom Sizes: 3.55″ x 5.83″ — 11.69″ x 17″ (90 x 148 mm to 297 x 431.8 mm) Envelopes for Tray 2: Com10, Monarch, C5, C6, DL; Envelopes for Optional Paper Feed Units: Com10, C5 Bypass Tray: User adjustable up to 12″ x 18″ including 5.5″ x 8.5″ to 11″ x 17″ (140 x 216 mm to 279 x 432 mm), A3, A4, A5, A6; Custom Sizes: 3.55″ x 5.83″ to 12″ x 23.6″ (90 x 148 mm to 305 x 600 mm) and Envelopes: Com10, Monarch, C5, C6, DL Optional 2,000-Sheet LCT and Optional 1,500-Sheet Side LCT: Fixed for Letter (8.5″ x 11″) (216 x 279 mm), A4 When Duplexing: 3.55″ x 5.83″ to 11.69″ x 17″ (90 x 148 mm x 297 x 431.8 mm) |
| Supported Paper Weights | Std. Trays, Opt. PFU and LCTs: 16 – 82 lb. Bond/170 lb. Index (60 – 300 g/m2) Bypass Tray: 14 – 82 lb. Bond/ 170 lb. Index (52 – 300 g/m2) When Duplexing: 14 – 68 lb. Bond/ 140 lb. Index (52 – 256 g/m2) |
| Supported Paper Types | All Sources: Plain Paper, Recycled Paper, Color Paper, Letterhead, Special Paper 1-3, Card Stock, Bond Paper, Preprinted Paper Envelopes: Com10 and C5 envelopes can be fed using Standard Trays, Bypass Tray and Optional Paper Feed Unit Bypass Tray Only: Labels, OHP |
| Duplexing | Automatic (standard) |
| Power Requirements | 120 – 127V, 60Hz, 15A |
| Power Consumption | Operating: 1600W or less Sleep Mode: 0.5 W or less ENERGY STAR® compliant |
| Typical Energy Consumption (TEC) | 0.75 kWh/week TEC value is measured based on the ENERGY STAR Ver.3.0 test method. |
| EPEAT status | Gold |
| Dimensions W x D x H | 23.1″ x 25.7″ x 28.3″ (587 x 653 x 720 mm) (Main Unit only) |
| Weight | 125.6 lb. (57 kg) (Main Unit only) |
Controller Specifications
| Processor Speed | Intel® Atom Processor BayTrail-1 1.46 GHz |
|---|---|
| Memory (Standard/Maximum) | Standard/Maximum: 2 GB/2 GB |
| Hard Disk Drive | 320 GB (optional) |
| Standard Interfaces | 10Base-T/100Base-TX/1000Base-T Gigabit Ethernet, High Speed USB, Dual USB 2.0 Host Type A, USB 2.0 Type A/SD Card Slot integrated into Smart Operation Panel (for Print from Portable Media) |
| Optional Interfaces | USB 2.0 Port, IEEE 1284, IEEE 802.11a/b/g/n* *Only one interface can be installed. |
| Printer Languages/Drivers | Standard: PCL5c, PCL6, PostScript3 emulation, PDF Direct Print emulation, Media Print (JPEG/TIFF), PJL, RPCS Optional: Genuine Adobe® PostScript®3™, PDF Direct from Adobe®, XPS |
| Font Support | Standard: PS3/PDF/PCL emulation — 80 Roman fonts + 13 International fonts Optional: Genuine Adobe PS3/PDF Direct — 136 Roman fonts |
| Network Protocols | Standard: TCP/IP (IPv4, IPv6) Optional: IPX/SPX |
| Supported Operating Systems | Windows Vista/7/8/8.1/10/Server 2008/Server 2008R2/Server 2012/Server 2012R2/2016 Citrix Presentation Server 4.5, Citrix XenApp 5.0+ Mac OS X v.10.9 or later, SAP R/3, Novel NetWare Server 6.5 (option is required), UNIX (using Ricoh UNIX filter) Sun Solaris 9/10, HP-UX 11.x/11i v2/11i v3, SCO OpenServer 5.0.7/6.0, RedHat Linux Enterprise V4/V5/V6, IBM AIX 5L version 5.3/6.1/7.1 |
| Device Management Software/Utilities | Device Manager NX Series, Web Image Monitor, @Remote |
| Controller Options | Extended USB Board Type M19, IEEE802.11a/g/n Interface Unit Type M19, IEEE1284 Interface Board Type M19, VM Card Type P13, XPS Direct Print Option Type P13, IPDS Unit Type P13*, HDD Option Type P13, Genuine Adobe PostScript3 Type P13 *Available after launch |
| Printer Features | Bonjour Support, Windows Active Directory Support, DDNS Support, PCL Resident Font Adoption, Tray-Parameter Change from Web Image Monitor, 1200 dpi Support, Universal Driver, XPS Support, WS Printer, Wireless LAN Interface Option, Media Direct Print (Print from USB/SD), Poster Print, WPS Support |
| Security Features | DataOverwriteSecurity System (DOSS), Authentication (Windows/ LDAP/Kerberos/Basic/User Code/802.1.x Wired), Wireless LAN Security (WPS/IEEE802.11i/IEEE802.11w), Encryption (Address Book/Authentication Password/SSL Communication/S/MIME/IPsec Communication/HDD/SMTP over SSL/TLS/Transport Layer Security/ SSH/Wireless LAN), Locked Print, Network Protocols ON/OFF, IP Address Filtering, Quota Setting/Account Limit, Compulsory Security Stamp, Unauthorized Copy Prevention and Mask Type for Copying |
